ATIKA ADH 204 surface and thickness planer | 230V | 1500W

ATIKA surface and thicknessing planer ADH 204 - the perfect helper for precise woodworking The ADH 204 from ATIKA is the ideal surface and thickness planer for precise woodworking.

Equipment:

• quick and easy angle adjustment of the stable dressing fence (0° - 45°)
• Suction bonnet can be easily converted from a surface planer to a thicknesser
• exact adjustment of the chip removal during surface and thickness planing
• with cable take-up and extendable workpiece support for thickness planing
• safe working due to zero voltage switch, motor switch and knife shaft cover
• including planing knife setting gauge, 2 sliding blocks and connection for dust extraction Ø 100 mm
• Easy and universal processing of wood
• Powerful motor
• Complete with suction bonnet
• compact construction

Technical details:

• alternating current motor: 230 V ~ 50 Hz
• Input power P₁: 1500 W
• Speed: 9000 min^-1
• Knife size: 210 x 16,5 x 1,5 mm
• Cutting height (thicknessing plane) max.: 5 - 120 mm
• Cutting width max.: 204 mm
• Chip removal during dressing max.: 3 mm
• Chip removal during thickness planing max.: 2 mm
• Table size: 270 / 740 x 210 mm
• Dimensions (length x width x height): 780 x 442 x 464 mm
• Protection class: IP 50
• Sound pressure level at the workplace LPA: 92,9 dB (A)
• Sound power level LWA: 105,9 dB (A)
• Measurement uncertainty factor K: 3 dB (A)
• weight: approx. 27,5 kg
